Documenting the evolution of a physical product is critical for maintaining design integrity. Our Prototype Notes module provides a structured environment to log every modification, from initial 3D prints to final pre-production samples. By capturing material properties, tolerance adjustments, and assembly feedback in real-time, engineering teams can trace the history of every component and avoid repeating past errors. This digital ledger bridges the gap between digital CAD models and physical reality.
Key Specifications
- Versioned Iteration Tracking
- Material Performance Logs
- Tolerance Adjustment History
- CAD to Prototype Correlation
Effective prototyping requires more than just making parts; it requires understanding why changes were made. Whether you are adjusting a wall thickness for better structural rigidity or modifying a snap-fit joint for easier assembly, every detail matters. The Prototype Notes module integrates into the broader OrbitDesign workflow, allowing users to reference specific CAD versions alongside physical test results. This ensures that the final handoff to manufacturing is backed by a complete history of validated design choices.
No registry entries found. This could be your first log entry.
